Maytag Front Load Washer Error Codes

Maytag Front Load Washer Error Codes – Maytag is a well-known appliance brand famous for its durability and trustworthy appliances. That being said, it doesn’t mean that your Maytag washer won’t run into any issues down the road. Appreciatively, Maytag washer error codes exist, making it easy to figure out what the issue is when a problem occurs.

During all the washer codes listed in your owner manual, we have compiled a list of the most common error codes and issues, what they mean, and how to troubleshoot them.

The Following Maytag Washer Models are Covers In This Guide:

A101

A102

A102S

A103

A103S

A104

LAT9416AAE

MAH3000AWW

MAH4000AWW

MAH5500BWW

MAH8700AWW

MAV6200AWW

MAV7600AWW

MHWE200XW00

MVWC300VW1

MVWC415EW2

MVWC6ESWW1

MVWX655DW1

PAV2200AWW

PAV2300AWW

PAVT234AWW

How To Clear An Error Code

How To Clear An Error Code

Separately from fixing the issue causing the error code, clearing an error code by unplugging the washer for a few minutes is often possible. Depending on the issue, when you rejoin the power, the error code will usually no longer be displayed (at least for now).

While the error code might have been clear, if the issue remains, the error code will ultimately appear again. It is essential to fix the problem rather than try to avoid it, which will likely cause more damage to the washer or flood the laundry.

However, occasionally, an error code causes by a control board glitch, in which case, disconnecting the power is all you need to do to fix the problem.

Error Codes For Maytag Washer Front-Loader

Error Codes For Maytag Washer Front-Loader

dET is showing in the Display:  Using the Finest Dispense Cartridge (on some models)

This error code shows that the detergent dispenser cartridge does not detect in the dispenser. If you are using single-load doses of detergent, ignore this message.

Ensure the dispenser cartridge inserts correctly, and the drawer shuts completely.

F5 E2: The Door Is Not Locked Correctly

You will find the requirement to review the door lock to resolve this issue. It may be as simple as shutting the door correctly, or you may need to replace the door lock.

Pressing the Pause or Cancel button two times and the Power button once may also clear the error code.

F7 E1 Code In The Display

This code indicates a motor speed sensing error, and the motor can not achieve the correct speed for the cycle selection.

F8 E1 Or Lo Fl Error Code

If the washer has an F8 E1 or LO FL error, the door will lock, and the control will be unresponsive. Press the push button, and the washer will start a drain routine which takes around 8 to 10 minutes, during which the pump will run continuously. The control will not accept any effort during this time. Please wait 10 minutes before trying to perform any functions.

F8 E2

This error code shows a problem with the dispenser system.

This is a common problem if too much detergent is used. You will need to clean the detergent drawer and regularly check for any detergent rest to stop this error from occurring.

F9 E1: Drain Times Are Lengthier Than Expected

The washer drains too long (usually more than eight minutes). A blocked drain pipe or an imperfect drain pump likely causes the issue. The incorrect detergent or a kink in the drain pipe can also cause the issue. A reparation expert may require to diagnose and fix the problem.

INT

This error code specifies the cycle has been paused or canceled.

After displaying this error code, your washer can take up to 30 minutes to stop spinning and drain. If the error does not clear, press the Pause or Cancel button twice and the Power button once.

RL Or F34

Remove items from the drum and start the Clean Washer cycle again.

LOC or LC

This error code shows the control lock is on.

If the control lock is on, your washer may be unable to change cycles or start. You will need to deactivate the control lock to solve the problem.

Sud Or Sd Is Displayed:

There are numerous suds in the washing machine, and the washer cannot spin out water with the extra suds. When “Sud” or “Sd” is displayed, the washer automatically covers the rinse time to remove the extra suds. During this time, the washer pauses the reduction and adds water for extra rinsing. This pause lets the bubbles in the suds break. This pause and rinsing are necessary and may occur several times to eliminate the suds.

Maytag Washer Top-Loader Error Codes

Maytag Washer Top-Loader Error Codes

DRN: The Washer Is Not Draining Properly

The drain pipe may be blocked or not installed to the correct specifications. The drain pump or a clogged internal filter may also have a problem.

HC: Hot And Cold Water Inlet Pipes Not Installed Correctly

The cold water pipe connects to the hot water inlet on the washer and vice-versa. Connect the pipes correctly to fix the issue.

LDL: The Washer Lid Is Not Locking

Check that the lid lock is not jammed and clean any detergent residue around it. The lid lock may need to replace.

LDU: The Washer’s Lid Can Not Unlock

Something on top of the washer is preventing the lid lock from being able to solve.

LF, LO FL, OR F8 E1: It takes a while for the washer to fill.

Check that the water stream to the washer turns on, the hot and cold faucets turn as far as they will go (completely open), and that the water inlet valve filters are not clogged.

LID: The Washer Lid Is Not Closed

Make sure the lid is closed correctly to resolve the error code. The lid assembly or switch may need replacing if the error code is left over.

OFB: The Load Is Unstable

The washer will stop the cycle and attempt to rebalance the load. You can help remove the error code faster by eliminating items or rebalancing the load.

OL: The Washer Is Overloaded

When the washer detects overloading, it will begin a drain cycle, after which you will need to remove objects and restart the wash cycle (as well as add detergent).

PF: During the wash cycle, there was a power failure.

To clear the error code, hold Start for ten seconds or press Power. Unplugging the washing machine for a few minutes should also resolve the problem.

Conclusion

If your Maytag washer error code is not listed above, a more severe issue is likely with a constituent inside the washer. Maytag guides that you check the washer’s manual and schedule a trained technician to troubleshoot the problem.
